Phi-Deck Tape Drives

The Triple-I division of the Economy Company made several different Phi-Deck models, with fixed or variable tape speeds. Some of their early low-cost models used a sheet-metal body, but the better ones (including those used by The Digital Group) were built on a rigid casting.

Phi-Deck drives were offered "bare", or with electronics. Since the Digital Group used them for digital saturation recording, they used the bare drive, together with their own controller card.

Phi-Deck drives are still available from Phi Technologies, although they are most commonly used for audio recording.


The casting of the drive used in The Digital Group's system references these US patents:

A search reveals that Triple-I and the Economy Company held other patents in this area, some of which may have also been relevant to the Phi-Deck drives:

(patent links courtesy of the IBM Intellectual Property Network)



The Phi-Deck was featured in the What's New column of BYTE magazine in April 1976. The item used the same photograph from the advertisement, with the caption:
Here is a product which will be of interest to many BYTE readers. This is an electronically controlled variable speed digital cassette deck which can be adapted for use by the home computer experimenter. It is made by Triple I, a division of the Economy Company, PO Box 25308, Oklahoma City OK 73125. Its price is in the $100 range and it should prove to be an excellent medium for totally automated data storage in personal computer systems.

It seems somewhat ironic that 22 years later 3.5 inch floppy disk drives with a formatted capacity of 1.44 megabytes sell for under $25 retail, less than a quarter of the price of a Phi-Deck. Technology marches on.
